AWP PNEUMATIC ULTRA FEATHER TOUCH

DWP
LVDT Gauge Probe | Ultra Feather Touch Pneumatic Push AW/P
  • Standard contact sensor tip force of 0.3N
  • ± 5mm displacement transducer measuring ranges
  • Linearity better than 0.5% of precision measurement
  • Repeatability precision better than 0.05 µm
  • Pneumatic actuation
  • IP50 sealing
  • Linear Variable Differential Transformer (LVDT) or Half Bridge options


  • The Ultra Feather Touch displacement probe has so light a tip force, it is a viable alternative to a non-contact sensor in many applications. With various tips available in ruby and nylon, the UFT displacement sensor is already being used to check glass, rubber, semi-conductor wafers and other delicate materials.
